Technical Specifications Supply voltage:24 V DC ±10%; Communication:EtherNet/IP,10/100Mbps; Operating pressure:0.4–10 bar(g); Operating temperature:-30 °C ~ +120 °C; Enclosure:IP65; Position resolution:16-bit.
Functional Features EtherNet/IP communication; embedded web server; high precision LVDT closed-loop control; remote configuration and diagnostic; data logging function.
Application Scenarios Smart power plant gas engine control, remote monitoring cogeneration unit, IIoT fuel management system.
Performance Parameters Flow linearity:±1.8% FS; Repeatability:±0.7% FS; Communication cycle:10 ms.
Material Composition Aluminum valve body; polished stainless steel plunger; FKM seals; high precision LVDT; EtherNet/IP controller board.
Structural Characteristics Inline flow body; top-mounted solenoid and Ethernet electronic unit; sealed RJ45 Ethernet connector.
Working Principle EtherNet/IP master sends target opening command. Onboard controller compares LVDT real-time position, adjusts solenoid current, upload valve status and diagnostic data over Ethernet network.
Installation Requirements Install inline vertically; connect Ethernet and 24V power; set IP address; calibrate zero and span.
