Technical Specifications Supply voltage:24 V DC ±10%; Communication:DeviceNet; Operating pressure:0.5–10 bar(g); Operating temperature:-30 °C ~ +120 °C; Enclosure:IP65; Equipped with 3200-5/P2 pressure sampling port fitting.
Functional Features Integrated pressure sampling port; DeviceNet digital control; LVDT closed-loop position feedback; remote fault diagnosis; zero shutoff.
Application Scenarios Gas engine fuel control requiring real-time gas pressure monitoring, cogeneration system with gas pressure measurement, large generator fuel regulation.
Performance Parameters Flow linearity:±2.2% FS; Repeatability:±1% FS; Response time:<22 ms.
Material Composition Aluminum valve body; stainless steel valve internals; FKM seals; DeviceNet electronic board; stainless steel 3200-5/P2 pressure tap fitting.
Structural Characteristics Inline flow valve body, side mounted 3200-5/P2 pressure sampling port; top solenoid and electronic assembly.
Working Principle DeviceNet command controls valve opening, LVDT feedback for closed-loop regulation; 3200-5/P2 port connects pressure transmitter to monitor gas inlet pressure.
Installation Requirements Install inline vertically; connect DeviceNet bus; mount pressure transmitter on 3200-5/P2 tap; calibrate valve and pressure circuit.
Usage Notes Keep pressure sampling pipeline clean; avoid condensate blockage of pressure tap; regularly check pressure port sealing.
