Technical Specifications Supply voltage:24 V DC ±10%; Communication:DeviceNet; Operating pressure:0.5–9 bar(g); Operating temperature:-30 °C ~ +120 °C; Enclosure:IP65.
Functional Features High flow capacity; DeviceNet digital communication; LVDT closed loop; remote diagnostics; zero shutoff.
Application Scenarios Large bore gas engine, heavy-duty cogeneration plant, high power gas generator set, pipeline compression engine.
Performance Parameters Flow linearity:±2.5% FS; Repeatability:±1.2% FS; Response time:<28 ms.
Material Composition Cast aluminum valve body; stainless steel plunger and seat; FKM seals; high thrust solenoid; DeviceNet electronic module.
Structural Characteristics Large caliber inline body; heavy-duty top solenoid assembly; DeviceNet fieldbus connector.
Working Principle DeviceNet host sends opening command. Onboard controller adjusts solenoid current based on LVDT position feedback, controls large volume gas flow.
Installation Requirements Install vertically inline; install large flow gas filter upstream; set DeviceNet node address, calibrate valve opening.
Usage Notes Ensure gas pipeline flow velocity within specification; inspect valve seat wear periodically.
