Technical Specifications 24VDC nominal power supply; built-in CT/PT AC sampling; abundant analog and discrete I/O; paralleling communication interface. Operating temperature: -40℃ ~ +85℃.
Functional Features Automatic engine start-stop sequence; generator over/under voltage and frequency protection; dead bus synchronization; isochronous and droop load sharing; timestamp event logging.
Application Scenarios Industrial power plants, grid-connected or island-mode diesel and gas generator control.
Performance Parameters High synchronizing precision, fast load regulation response, comprehensive protection interlock, stable parallel running performance.
Structural Characteristics Panel mount metal housing, front LCD display and operation keypad, screw type wiring terminals.
Working Principle The controller continuously samples generator and bus electrical parameters, monitors engine operating status. It executes start-stop logic, completes synchronizing during paralleling, distributes load evenly and triggers trip protection once fault occurs.
Installation Requirements Flush panel mounting; separate AC sampling wiring and high-power cables; reliable protective earthing.
Usage Notes Backup all configuration parameters before modifying settings; test protection and synchronizing function during commissioning.
