Technical Specifications Supply voltage:24 V DC ±10%; Control input:4–20mA; Position feedback:4–20mA; Operating pressure:0.5–11 bar(g); Operating temperature:-35 °C ~ +125 °C; Enclosure:IP65; Vibration withstand:25g peak.
Functional Features Enhanced anti-vibration mechanical structure; closed-loop LVDT position feedback; low friction moving assembly; full shutoff; wide temperature range.
Application Scenarios Heavy-duty gas engines, engine direct-mounted fuel control, field compressor engines, high vibration cogeneration units.
Performance Parameters Flow linearity:±2.2% FS; Repeatability:±0.8% FS; Response time:<22 ms.
Material Composition Reinforced aluminum valve body; hardened stainless steel plunger; FKM high temperature seals; reinforced solenoid assembly.
Structural Characteristics Inline flow structure; reinforced top electronic housing; anti-loose fasteners; threaded process ports.
Working Principle Same closed-loop position control principle as 8440-1855F, with mechanical reinforcement of moving parts and fasteners to resist engine vibration without position drift.
Installation Requirements Mount inline vertically; tighten all fasteners to specified torque; use shielded analog wiring; calibrate zero and span after installation.
