Technical Specifications Supply: 24 V DC ±10%; communication: EtherNet/IP, 10/100 Mbps; flow range: 0–45 kg/h natural gas; operating pressure: 0.5–10 bar(g); operating temperature: -30 °C to +120 °C; enclosure: IP65; position resolution: 16-bit.
Functional Features EtherNet/IP connectivity; closed-loop position control; remote monitoring and configuration; embedded web server; fault diagnostics; data logging.
Application Scenarios IIoT-enabled engine control, Ethernet-based plant automation, remote fuel monitoring, smart cogeneration plants, industrial internet of things applications.
Performance Parameters Flow accuracy: ±2% FS; communication cycle time: 10 ms; position resolution: 16-bit; web server refresh: 1 s.
Material Composition Aluminum valve body; stainless steel internals; precision position sensor; Ethernet controller; solenoid drive.
Structural Characteristics In-line flow body; top-mounted control module; RJ45 Ethernet connector; threaded process connections.
Working Principle The embedded EtherNet/IP stack receives control commands over the network, executes closed-loop position control, and provides process data, diagnostics and configuration access via an embedded web server and explicit messaging.
Installation Requirements Install inline with flow arrow; connect Ethernet and power cables; configure IP address and network parameters; calibrate valve during commissioning.
