Technical Specifications Power supply 18–32 Vdc; True RMS voltage and current measurement for 50/60Hz; 8 isolated discrete inputs, 6 relay outputs; CAN bus and RS232 communication; 4-line backlit LCD display. Operating temperature -40℃ ~ +85℃.
Functional Features Generator synchronization, real and reactive load sharing, breaker control, over/under voltage and frequency protection, fault alarm and event recording, parameter configuration via front keypad.
Application Scenarios Industrial generator sets, parallel power generation systems and mains interconnection cabinets.
Performance Parameters High precision voltage/current sampling, fast synchronization response, reliable relay contact output.
Structural Characteristics Front panel flush mounting metal housing, membrane keypad, pluggable wiring terminals.
Working Principle Continuously measure generator and bus voltage, frequency and phase angle, calculate synchronization condition and output commands to close circuit breaker, realize load distribution after paralleling.
Installation Requirements Install on control cabinet front panel, separate power and signal wiring, use shielded cable for AC sampling signals.
Usage Notes Check CT and PT wiring before commissioning; regularly test protection functions.
