Technical Specifications 9–32VDC wide range power supply; CT/PT AC sampling; digital input and relay output; serial communication interface. Operating temperature: -40℃ ~ +85℃.
Functional Features Automatic start-stop sequence; over/under voltage and over/under frequency protection; dead bus synchronization; isochronous and droop load sharing; timestamp fault event recording.
Application Scenarios Stationary diesel and gas generator control cabinets, single unit or parallel generation systems.
Performance Parameters Stable logic execution, reliable electrical protection, high precision power measurement and load distribution.
Structural Characteristics Metal enclosure, panel or DIN rail mounting, pluggable terminal connectors.
Working Principle The module samples generator voltage, current and engine speed signals, runs start-stop sequence and protection logic. During parallel operation, it communicates with peer controllers to complete synchronization and load balancing.
Installation Requirements Separate AC sampling cables, power cables and weak signal cables; proper shield grounding.
Usage Notes Check CT and PT polarity before commissioning; backup configuration parameters before firmware update.
