Technical Specifications Input: magnetic pickup, 50 mV–30 V AC, 10 Hz–20 kHz; output: square wave timing trigger, 24 V DC level; supply: 24 V DC ±10%; signal loss detection; operating temperature: -40 °C to +85 °C; IP20 enclosure.
Functional Features Wide input amplitude range; precision signal shaping; speed-proportional square wave output; signal loss detection and alarm; noise filtering.
Application Scenarios Ignition system speed input, engine timing reference, speed signal conditioning for ignition control, engine speed monitoring.
Performance Parameters Frequency accuracy: ±0.02%; trigger jitter: < 1 µs; signal loss response: < 10 ms; rise/fall time: < 2 µs.
Material Composition Industrial plastic housing; signal conditioning circuit; opto-isolated output; screw terminals.
Structural Characteristics Rack plug-in module; front status LED; rear terminal block.
Working Principle Conditions and shapes the sinusoidal magnetic pickup signal into a clean square wave timing reference, providing a stable speed and position reference for the ignition controller.
Installation Requirements Mount in control rack; connect shielded pickup cable; wire timing output to ignition controller; configure trigger threshold.
