Technical Specifications Supply: 18–32 V DC; input: timing trigger signal; output: 6 channel coil drive, 10 A peak per channel; dwell range: 0.5–20 ms; operating temperature: -40 °C to +85 °C; enclosure: IP54; input trigger: 5 V to 24 V logic level.
Functional Features Multi-channel coil drive; precision dwell control; current limiting; over-temperature protection; short-circuit protection per channel; trigger input isolation.
Application Scenarios Multi-cylinder engine ignition drive, ignition system power stage, industrial gas engine upgrades, distributed ignition systems.
Performance Parameters Dwell accuracy: ±2%; current regulation: ±5%; rise time: < 5 µs; fault response: < 1 ms.
Material Composition Metal baseplate; power semiconductor output stage; control logic circuit; sealed connector.
Structural Characteristics Bracket mountable; multi-pin input/output connector; integral heat sink; status indicators.
Working Principle Receives timing trigger signals, controls coil dwell time and current to deliver consistent spark energy, and provides per-channel protection against short circuit and overtemperature.
Installation Requirements Mount with thermal interface to heat sink; connect trigger input and coil outputs; set dwell per coil specification; verify current limit.
