Technical Specifications Compatible with 8290 series plug-in relays; current rating: 10 A per pole; voltage rating: 300 V AC maximum; connection: screw clamp terminals; mounting: 35 mm DIN rail; operating temperature: -40 °C to +85 °C; material: thermoplastic base, copper alloy terminals.
Functional Features Secure plug-in relay retention; screw clamp terminal connection; DIN rail and panel mount options; finger-safe terminal design; marking for circuit identification.
Application Scenarios 8290 series relay mounting, control cabinet relay assemblies, industrial panel wiring, replaceable relay installations.
Performance Parameters Contact resistance: < 5 mΩ; withstand voltage: 3000 V AC; terminal retention force: > 50 N per wire.
Material Composition Thermoplastic insulating base; copper alloy current bars; screw clamp terminals; retention clips.
Structural Characteristics DIN rail mountable base; screw-accessible top terminals; relay retention clips; circuit identification markers.
Working Principle Provides a secure mechanical and electrical interface for plug-in relay modules, with screw terminals for field wiring and retention clips to hold the relay in place.
Installation Requirements Snap onto 35 mm DIN rail; torque terminal screws to 0.5–0.7 N·m; plug relay module firmly into socket; verify seating before energizing.
