Technical Specifications 24VDC working power; multi-channel signal interfaces; non-volatile memory for parameter and event storage; hardware watchdog circuit. Operating temperature: -40℃ ~ +85℃.
Functional Features Multi-source sensor signal processing; governing and safety protection logic operation; communication data exchange with upper monitoring system; fault diagnosis and timestamped event recording.
Application Scenarios Gas turbine, gas engine and large genset master control cabinets.
Performance Parameters High computing efficiency, stable operation under strong electromagnetic interference, reliable data storage.
Structural Characteristics Rack pluggable PCB, built-in shielding layer, onboard terminal blocks for signal connection.
Working Principle The board receives all field sensor and I/O signals, executes preset control and protection algorithms, distributes output commands to each I/O module, and communicates with HMI and SCADA systems.
Installation Requirements Install in well-ventilated cabinet, away from heat sources and strong EMI sources; wear anti-static wristband during replacement.
Usage Notes Backup all configuration parameters before board replacement; check communication bus connection after commissioning.
