Technical Specifications 24VDC power supply, frequency pulse signal input, digital communication output. Operating temperature: -40℃ ~ +70℃.
Functional Features Pulse signal shaping, speed value calculation, overspeed alarm, signal loss detection.
Application Scenarios Gas engine, diesel generator and rotating machinery speed monitoring system.
Performance Parameters High speed resolution, strong anti-interference ability for pulse noise.
Structural Characteristics PCB board with gold-plated edge connector and built-in signal conditioning circuit.
Working Principle Receive pulse signals from speed sensor, filter interference signals, calculate real-time rotational speed and transmit data to main controller.
Installation Requirements Speed signal cable adopts shielded twisted pair, avoid parallel laying with power cables.
Usage Notes Check the air gap between magnetic pickup and gear before commissioning.
