Technical Specifications Input: 100 mV–25 V AC, 20 Hz–50 kHz; Output: 24 V DC square wave; Supply: 24 V DC ±10%; signal loss detection; Operating temperature: -40 °C to +85 °C; Enclosure: IP20.
Functional Features Wide high-frequency range; signal filtering and shaping; overspeed threshold detection; high noise immunity; low phase shift.
Application Scenarios Gas turbine speed monitoring, high-speed turbo control, centrifugal compressor overspeed protection, high-speed rotating test stands.
Performance Parameters Frequency range: 20 Hz–50 kHz; Phase shift: < 1°; Rise time: < 1 µs; Frequency accuracy: ±0.01%.
Material Composition Metal shielded enclosure; high-frequency conditioning circuit; high-speed opto-couplers; shielded terminals.
Structural Characteristics Rack plug-in form factor; metal shielded body; front panel status LED; rear high-frequency terminals.
Working Principle Uses high-frequency dedicated conditioning circuits and high-speed isolation devices to shape and isolate high-speed speed pulses, outputting standard digital square wave signals.
