Technical Specifications 24VDC power supply; multi-channel isolated analog and digital signals; overvoltage and overcurrent protection; working temperature -40℃ ~ +70℃.
Functional Features Signal galvanic isolation, signal filtering, real-time channel status monitoring, abnormal signal alarm.
Application Scenarios Steam turbine, gas turbine and generator set control system, industrial prime mover control cabinet.
Performance Parameters High isolation strength, short signal response time, stable long-distance signal transmission.
Structural Characteristics DIN rail installation structure, pluggable terminal connectors, compact circuit board assembly.
Working Principle Receive field switching and analog measurement signals, filter and isolate the signals and transmit to main controller; convert control commands from main controller into output signals to drive field devices.
Installation Requirements Ensure good ventilation inside the cabinet, avoid heavy dust accumulation, fix the module reliably against vibration.
Usage Notes Check channel integrity after wiring; power off before plugging or unplugging the module.
