Technical Specifications 24VDC power supply; multi-range analog signal input and output; galvanic isolation between input and output sides. Operating temperature: -40℃ ~ +70℃.
Functional Features Analog signal range conversion; electrical isolation between field and control side; noise filtering; overrange protection.
Application Scenarios Turbine, gas engine and genset control cabinet signal matching and isolation.
Performance Parameters Low conversion error, high isolation voltage, stable signal transmission under EMI environment.
Structural Characteristics DIN rail metal housing, pluggable screw terminals, isolation circuit integrated on PCB.
Working Principle Input analog signal passes through isolation and conversion circuit. Signal range is adjusted to standard value, and electrical isolation is realized to eliminate ground loop interference before sending to governor.
Installation Requirements Separate analog signal cables and power cables; properly ground shielding terminal.
Usage Notes Calibrate input and output range before putting into service; avoid overvoltage input.
