Technical Specifications Supply: 24 V DC ±10%; speed input: magnetic pickup, 100–10,000 Hz; actuator output: 0–10 A; control resolution: 12-bit; operating temp: -40 °C to +80 °C; IP65.
Functional Features Integrated speed governor + actuator drive; PID speed control; overcurrent protection; speed fault detection; compact all-in-one design.
Application Scenarios Small engine speed control, pump drive governing, compact generator set control, integrated throttle control.
Performance Parameters Speed regulation: ±0.5% FSO; current accuracy: ±1.5% FSO; response time: < 200 ms.
Material Composition Die-cast aluminum housing; integrated control and power stage; sealed connectors.
Structural Characteristics Engine-mountable design; integrated connector; mounting flanges.
Working Principle Integrates speed sensing, PID governor control and actuator power drive in one unit, directly controlling the electric actuator to maintain engine speed.
Installation Requirements Mount directly to engine; connect speed pickup, actuator and power; configure setpoints and gain.
Usage Notes Ensure mounting is rigid; calibrate speed and stroke during commissioning; protect connector from moisture.
