Woodward 8239-019 Auxiliary Logic Board

Technical Specifications 24VDC power supply, multi-channel discrete signal input and output. Operating temperature: -40℃ ~ +70℃.

Functional Features Logic judgment, signal latching, interlock control, fault transfer output.

Application Scenarios Turbine and genset safety interlock auxiliary control loop.

Performance Parameters Stable logic operation, anti-surge, long service life.

Structural Characteristics PCB board with gold-plated edge connector, moisture-proof conformal coating.

Working Principle Receive switch status signals, execute preset logic program, output control signal to realize interlock protection.

Installation Requirements Anti-static protection during installation, fully insert into rack slot and lock.

Usage Notes Do not arbitrarily modify interlock logic, regularly check connector contact.
