Technical Specifications Supply: 24 V DC ±10%; input: 4–20 mA / Modbus RTU; output: 0–3 A proportional; 12-bit resolution; dither: software configurable; RS-485 Modbus; -40 °C to +85 °C; IP40.
Functional Features Digital closed-loop current control; software configurable dither; Modbus monitoring/configuration; fault diagnostics; auto-zero.
Application Scenarios Networked valve control, precision hydraulic systems, digitally configurable valve drives.
Performance Parameters Current accuracy: ±0.3% FSO; resolution: 12-bit; response time: < 12 ms.
Material Composition Sheet metal housing; digital control PCB; power output stage; Modbus transceiver.
Structural Characteristics DIN rail mount; front status LEDs; rear terminal block and comm port.
Working Principle Digital controller samples output current, adjusts PWM output stage to maintain precise proportional current; parameters configurable via Modbus.
Installation Requirements Mount on DIN rail; connect valve, power and Modbus; configure via service tool.
Usage Notes Configure dither and gain via Modbus; backup configuration; perform periodic diagnostic reads.
