Technical Specifications Supply: 18–32 V DC; speed input: 1 channel, 5 Hz–15,000 Hz; 2× 4–20 mA outputs; 6 inputs / 4 outputs; 16-bit resolution; -40 °C to +70 °C; IP20.
Functional Features High-resolution PID; dual matched analog outputs; configurable output mapping; enhanced diagnostics; multi-setpoint selection.
Application Scenarios Dual-actuator turbine control, split fuel systems, precision multi-element governors.
Performance Parameters Speed regulation: ±0.25% FSO; output matching: ±0.5% FSO; transient response: < 200 ms.
Material Composition Flame-retardant housing; FR-4 PCB; 16-bit MCU; dual precision output stages.
Structural Characteristics Rack plug-in module; front status LEDs; rear terminal block.
Working Principle Executes high-resolution speed control and outputs two proportional 4–20 mA signals for dual actuators.
Installation Requirements Connect both actuator circuits; calibrate output matching during commissioning.
Usage Notes Match output scaling to actuator requirements; calibrate channels annually.
