Technical Specifications Supply: 18–32 V DC; speed input: 1 channel, 5 Hz–15,000 Hz; 1× 4–20 mA output; 6 inputs / 4 outputs, 24 V DC; 16-bit resolution; 5 ms loop update; -40 °C to +70 °C; IP20.
Functional Features High-resolution PID control; fast loop update; enhanced diagnostics; multi-setpoint selection; adaptive gain; speed fault detection.
Application Scenarios Precision engine speed control, turbine governing, high-accuracy industrial drives.
Performance Parameters Speed regulation: ±0.25% FSO; measurement accuracy: ±0.05%; loop update: 5 ms.
Material Composition Flame-retardant plastic housing; FR-4 PCB; 16-bit MCU; precision analog output.
Structural Characteristics Rack plug-in module; front status LEDs; rear terminal block.
Working Principle High-speed loop executes PID control with 16-bit resolution for precise speed regulation and improved dynamic response.
Installation Requirements Mount in control rack; connect speed pickup and actuator; configure gain and setpoints.
Usage Notes Tune for specific engine response; verify speed accuracy with calibrated tachometer.
