Technical Specifications Supply: 18–32 V DC; speed input: 1 channel, 5 Hz–15,000 Hz; 1× 4–20 mA output; 8 inputs / 6 outputs, 24 V DC; 16-bit resolution; firmware V8; -40 °C to +70 °C; IP20.
Functional Features Adaptive PID with gain scheduling; expanded diagnostics & event logging; multi-setpoint selection; soft start / load sharing; field-upgradable firmware.
Application Scenarios High-performance engine control, variable speed drives, turbine governing, critical generator sets.
Performance Parameters Speed regulation: ±0.25% FSO; loop update: 5 ms; transient response: < 200 ms.
Material Composition Flame-retardant housing; high-density FR-4 PCB; 16-bit enhanced MCU; precision output stage.
Structural Characteristics Rack plug-in form factor; front status/fault LEDs; rear terminal block; firmware upgrade port.
Working Principle Runs adaptive PID with gain scheduling across speed range; high-resolution speed measurement and control output; comprehensive diagnostic monitoring.
Installation Requirements Configure setpoints and dynamics; verify firmware version; perform full tuning procedure.
Usage Notes Document firmware version; use only approved upgrades; backup config before firmware update.
