Woodward 6945-672 Relay Output Terminal Board

Technical Specifications 24VDC control side, relay contact output terminals. Operating temperature: -40℃ ~ +70℃.

Functional Features Control signal transfer, relay contact isolation, load terminal distribution, action status indication.

Application Scenarios Generator alarm output, emergency shutdown solenoid drive, turbine auxiliary equipment control loops.

Performance Parameters Stable relay action, clear status indication, convenient maintenance and testing.

Structural Characteristics Terminal PCB board with integrated relay units, screw terminals for field load wiring.

Working Principle Control signals from the I/O module trigger the relays on this terminal board. The relay contacts switch the external load circuit and the LED lights show the action status.

Installation Requirements Load wiring must match relay contact rating, keep away from combustible materials.

Usage Notes Do not overload relay contacts, check contact burn condition during routine maintenance.
