Technical Specifications 24VDC power supply, magnetic pickup frequency input, analog drive output. Operating temperature: -40℃ ~ +70℃.
Functional Features Speed pulse shaping, closed-loop governing calculation, actuator drive output and fault alarm.
Application Scenarios Industrial diesel engine and gas engine genset governing control cabinet.
Performance Parameters High speed measurement accuracy and fast dynamic adjustment response.
Structural Characteristics PCB board with gold-plated edge connector and anti-interference circuit layout.
Working Principle Receive the pulse signal from the magnetic speed sensor, calculate the speed deviation, and output a drive signal to adjust the fuel supply.
Installation Requirements Anti-static protection during installation, and shielded wire for speed signal.
Usage Notes Check the air gap between the magnetic pickup and the gear teeth before startup.
