Technical Specifications 24VDC power supply; voltage and frequency signal input; built-in synchronization logic circuit, communication interface.
Functional Features Automatic synchronization detection, speed and voltage trim command output, synchronization alarm, anti-parallel misoperation interlock.
Application Scenarios Industrial generator set cabinet, generator grid-connection control system.
Performance Parameters High phase detection accuracy, fast synchronization judgment, reliable anti-misoperation protection.
Structural Characteristics Rack-mounted industrial module, metal shielding shell, voltage signal dedicated terminal.
Working Principle Collect generator voltage and grid voltage signals, compare frequency, amplitude and phase difference, output adjustment signal to governor and excitation system to complete synchronization.
Installation Requirements Install in generator control cabinet, voltage signal wiring adopts shielded cable, ensure correct phase sequence.
Usage Notes Verify phase sequence before commissioning; regularly test synchronization function.
