Technical Specifications 24VDC power supply; pulse signal input from magnetic pickup; galvanic isolation between input and output. Operating temperature: -40℃ ~ +70℃.
Functional Features Speed pulse signal isolation; noise filtering; signal waveform shaping; overvoltage protection.
Application Scenarios Turbine, gas engine and diesel genset speed measurement and protection systems.
Performance Parameters High isolation voltage, low signal attenuation, stable pulse transmission under EMI environment.
Structural Characteristics DIN rail metal housing, pluggable screw terminals, built-in isolation circuit.
Working Principle The raw pulse signal from magnetic pickup enters the module, passes through isolation and filtering circuit, then clean isolated pulse signal is sent to the downstream control equipment.
Installation Requirements Install near speed sensor; separate signal wiring and high-current power cables.
Usage Notes Check pulse signal waveform during commissioning; inspect wiring shielding integrity regularly.
