Technical Specifications Supply voltage: 24 V DC ±10%; control input: 4–20 mA analog; output torque: 200 lb-ft nominal; rotational stroke: 90° standard; full stroke time: 400 ms; position feedback: integrated LVDT; operating temperature: -40 °C to +85 °C; enclosure: IP66; continuous duty rating.
Functional Features Brushless DC motor drive; closed-loop position control; integral position feedback; overload protection; over-temperature protection; zero and span calibration.
Application Scenarios Large engine fuel control, industrial damper positioning, large process valve actuation, turbine bypass valve control, heavy industrial motion control.
Performance Parameters Position accuracy: ±0.25% full stroke; repeatability: ±0.1%; step response: < 350 ms for 90°; stall torque: 300 lb-ft maximum.
Material Composition Cast iron housing, heavy-duty brushless DC motor, epicyclic gear train, precision LVDT sensor, alloy steel output shaft, high-temperature shaft seals.
Structural Characteristics Heavy-duty rotary output shaft with double keyway; four-bolt mounting flange; integrated control electronics compartment; sealed cable entry; heavy-duty bearing system.
Working Principle The actuator receives a 4–20 mA position command, drives a brushless motor through a heavy-duty gear train to rotate the output shaft, and an internal LVDT sensor provides precise position feedback for closed-loop control.
