Technical Specifications PCI slot powered. Profibus / MPI interface. Support S7 communication protocol. Operating temperature:0°C ~ +50°C.
Functional Features PC to S7 PLC data exchange. Real-time read/write PLC memory. Bus diagnostic function. Communication status LED.
Application Scenarios Industrial HMI PC, data acquisition system, factory monitoring workstation, old S7 PLC data collection.
Performance Parameters Real-time communication, reliable Profibus/MPI data transmission. Operating temperature:0~+50°C.
Structural Characteristics PCI form factor circuit board, DB bus connector, onboard protocol processing chip.
Working Principle Installed in industrial PC PCI slot, act as communication interface to exchange tags, data and alarm information between PC and Siemens S7 PLC through Profibus or MPI bus.
Installation Requirements Insert card into industrial PC PCI slot. Install driver software. Connect Profibus/MPI bus cable and set station address.
Usage Notes Install ESD protection before handling card. Configure bus parameters matching PLC side.
