Technical Specifications 16 independent PID loops. Support thermocouple, RTD, 4-20mA and voltage analog input. 1.5 samples per second per channel. RS232/RS485 serial communication. 100-240VAC power. Operating temperature:0°C ~ +50°C.
Functional Features 16-loop independent PID control. Ramp/soak recipe programming. Sensor failure and process alarm. Recipe selection via digital input. Remote data access via serial communication.
Application Scenarios Large multi-zone furnaces, semiconductor thermal processing, environmental test racks, multi-channel thermal test equipment.
Performance Parameters High density multi-point measurement, stable PID regulation. Operating temperature:0~+50°C.
Structural Characteristics DIN rail mount controller, front panel display and keypad, multi-row terminal block for 16 field sensor connections, processor and signal conditioning circuit.
Working Principle Sequentially sample 16 temperature measurement channels, run independent PID closed-loop calculation for each loop, adjust control outputs and upload temperature data to supervisory system.
Installation Requirements Mount on DIN rail inside control cabinet. Connect all 16 sensor and output wiring. Configure channel parameters in software or local keypad.
Usage Notes Arrange cable routing to reduce cross-talk between sensor channels. Check loop isolation for long sensor runs.
