Technical Specifications 16 signal channels, compatible with vibration and displacement sensors, relay output, backplane bus communication, 24V DC power.
Functional Features Field sensor signal acquisition, signal conditioning, relay alarm output, channel fault self-diagnosis.
Application Scenarios Multi-point vibration monitoring for large fans, pumps, turbines and other rotating machinery.
Performance Parameters Multi-channel synchronous sampling, built-in signal filtering, high channel isolation, stable signal collection.
Material Composition Flame retardant plastic housing, fiberglass PCB, copper terminal blocks, metal shielding frame.
Structural Characteristics Rack plug-in card, front terminal block for field wiring, rear gold finger for backplane bus.
Working Principle Receive analog signals from field sensors, perform signal conditioning, transmit processed data to CPUM processor via backplane bus and execute relay alarm output according to processor command.
Installation Requirements Insert module into VM600 rack, connect sensor shielded cables to terminal block, lock module.
Usage Notes Use dedicated sensor cables. Check channel wiring to prevent short circuit. Keep signal cables separated from power cables.
