Technical Specifications Power supply: 24V DC. Channel quantity:8 channels. Contact rating: 250VAC / 2A per point. Operating temperature:0~+60°C. Isolation between channels.
Functional Features Relay contact output supporting AC and DC loads. Independent channel isolation. LED status indication. Relay contact life monitoring. Short circuit protection.
Application Scenarios Industrial automation, auxiliary equipment control, fire and safety interlock, low power contactor control.
Performance Parameters Relay mechanical life: 10,000,000 operations. Electrical life: 100,000 operations at rated load. Operating temperature:0~+60°C.
Structural Characteristics Plug-in rack module, front LED indicators, relay terminal block, backplane connector, built-in mechanical relay components.
Working Principle PLC CPU sends switch command, module drives internal relay coil, relay contact closes or opens to connect or disconnect field load circuit.
Installation Requirements Mount in Toshiba PLC rack. Separate power wiring for relay loads. Check terminal tightening torque.
