Technical Specifications Power supply: 24V DC. Output channel:16 channels. Output type: transistor output. Rated load: 0.3A per channel. Operating temperature:0~+60°C. Isolation: group isolation.
Functional Features 16-channel transistor discrete output. Over-current protection for each channel. LED channel status display. Output circuit fault diagnosis. Anti-surge design.
Application Scenarios Factory automation, material handling equipment, production line valve and relay drive control.
Performance Parameters Single channel max current:0.3A. Response time <1ms. Isolation voltage 500V AC. Operating temperature:0~+60°C.
Structural Characteristics Rack plug-in module, front status LEDs, field terminal block, backplane gold pin connector.
Working Principle Receive control commands from PLC CPU via backplane bus, switch each transistor output channel on or off to actuate field loads, and feed back fault signals.
Installation Requirements Install in Toshiba PLC rack. Wire field loads to output terminals. Complete reliable ground connection.
