Technical Specifications Power supply: 24V DC. Flame signal input. Relay output for ignition and fuel valve. Operating temperature:0~+60°C.
Functional Features Automatic burner ignition sequence. Flame signal monitoring. Fuel valve safety interlock. Fault lockout and alarm. LED fault indication.
Application Scenarios Industrial boiler, furnace, heater burner safety control and flame monitoring.
Performance Parameters Flame response time <1s. Operating temperature:0~+60°C.
Structural Characteristics PCB control board, terminal block for power, flame sensor and actuator, LED status indicators.
Working Principle Execute pre-purge, ignition and flame detection sequence. If flame lost, cut off fuel valve immediately and trigger safety lockout.
Installation Requirements Install inside burner control cabinet. Connect flame detector, ignition transformer and fuel valve wiring.
Usage Notes Regular flame signal test. Never bypass safety interlock. Follow local combustion safety regulations.
