Technical Specifications Universal AC input 85–264 VAC, 5V DC output at 1A rated current, operating temperature -25°C to +71°C, overvoltage and overcurrent protection, PCB mount package.
Functional Features Wide input voltage range, constant voltage output, built-in protection circuits, high efficiency, low no-load power consumption.
Application Scenarios Industrial control circuits, sensor power supply, building automation, low-power industrial electronic devices.
Performance Parameters High conversion efficiency, low output ripple, stable output under wide input variation, long service life.
Material Composition Fiberglass PCB base, ferrite transformer, electrolytic capacitors, semiconductor components, plastic insulation.
Structural Characteristics Compact PCB mount package, pin type output terminals, lightweight design, encapsulated component layout.
Working Principle Converts AC input to regulated DC output through flyback switching topology, with optocoupler isolated feedback for stable voltage control.
Installation Requirements Mount on printed circuit board, solder pins properly, ensure input fuse protection, keep away from heat generating components.
Usage Notes Do not exceed rated output current. Verify input voltage before power on. Allow sufficient creepage distance from high voltage circuits.
