Technical Specifications Contact form: DPDT (2 Form C); contact rating: 10A at 600V AC, 0.5A at 250V DC; operating force: 2.2 lbs nominal; actuator type: side rotary lever; operating temperature range: -40°C to +85°C; IP67 enclosure rating; mechanical life: 10 million operations minimum; UL, CSA, IEC certified.
Functional Features Positive break contact action; sealed contact block for dust and moisture resistance; reversible actuator; gold-plated contact option for low-level signals; wide temperature tolerance.
Application Scenarios Conveyor end-of-travel sensing, machine tool position control, material handling equipment limit sensing, packaging machine position detection, heavy industrial process equipment.
Performance Parameters High repeatability accuracy; reliable operation under vibration and shock; long mechanical and electrical service life; stable contact resistance.
Material Composition Zinc die-cast housing, silver alloy contacts, copper terminal screws, nitrile rubber shaft seal, steel actuator lever.
Structural Characteristics Heavy-duty enclosed housing, side rotary actuator arm, top and bottom cable entry options, standard mounting foot pattern.
Working Principle When the machine actuator moves the switch lever, the internal cam mechanism transfers motion to the contact block, changing the state of the normally open and normally closed contacts to indicate position.
