Technical Specifications 24V DC coil voltage, specified holding torque, IP54 protection grade, matching SEW 31 series gear motors.
Functional Features Power-off braking, spring applied holding brake, fast response, wear resistant friction lining.
Application Scenarios Conveyor systems, material handling equipment, crane hoist mechanisms, positioning drive systems.
Performance Parameters Reliable holding torque, fast braking response time, long service life friction material, stable performance under temperature variation.
Material Composition Cast iron housing, spring assembly, electromagnetic coil, friction brake lining, steel hub.
Structural Characteristics Flange mounted brake assembly, integrated coil and friction disc, motor shaft through-hole design.
Working Principle When energized, the electromagnetic coil attracts the armature to release the brake; when power is cut off, the spring presses the friction disc to generate braking torque and hold the motor shaft.
Installation Requirements Mount on motor end flange, align shaft and hub correctly, adjust air gap according to specification, connect brake power cable.
Usage Notes Check air gap periodically during maintenance. Replace friction lining when worn to limit. Do not use brake for continuous dynamic braking.
