Technical Specifications Single-phase 220V AC supply, 50 Hz; rated motor power 60 W; rated motor speed 1400 rpm; gear reduction ratios available from 25:1 to 180:1; 24V DC electromagnetic brake; IP54 enclosure protection; class E insulation; foot mounting configuration; built-in 4µF/500VAC capacitor.
Functional Features Integrated gearmotor design; spring-applied electrically released brake; high starting torque; low noise helical gearing; capacitor-run single-phase operation; compact installation footprint.
Application Scenarios Small conveyor systems, packaging machinery, food processing equipment, material handling devices, light industrial machine drives.
Performance Parameters High torque density at low output speed; low backlash gearing; reliable brake holding torque; continuous duty S1 operation rating; low vibration operation.
Material Composition Aluminum gear housing, silicon steel stator laminations, copper motor winding, steel output shaft, sintered steel gear wheels, plastic motor end cover.
Structural Characteristics Coaxial helical gear unit directly coupled to motor; integrated brake assembly at motor rear end; foot mounting flange; top-mounted terminal box; solid output shaft with keyway.
Working Principle The single-phase capacitor-run motor converts electrical energy into rotational mechanical energy. The helical gear unit reduces rotational speed and multiplies output torque. The electromagnetic brake holds the shaft stationary when de-energized and releases it when energized.
