Technical Specifications Three-phase AC power input, multiple feedback interfaces, pulse and fieldbus control modes, built-in protection circuit.
Functional Features Position, speed and torque closed-loop control, electronic gearing, auto-tuning, fault diagnosis and alarm.
Application Scenarios Machine tool, packaging equipment, printing machinery, automated assembly lines.
Performance Parameters High control bandwidth, fast dynamic response, strong overload capacity, low speed ripple.
Material Composition Metal steel casing, IGBT power module, fiberglass control board, plastic terminal insulating housing.
Structural Characteristics Vertical panel mounting structure, front operation panel, power and signal terminal blocks, encoder interface.
Working Principle Receive motion command from upper controller, convert DC bus voltage into variable frequency three-phase AC to drive servo motor, realize closed-loop control with encoder feedback.
Installation Requirements Mount inside control cabinet, reserve heat dissipation space, use shielded cables for motor and encoder wiring.
Usage Notes Complete motor parameter configuration before commissioning. Check grounding and EMC measures before power on.
