Technical Specifications Power supply: 24V DC. Digital I/O and encoder interface. Pulse command output. Operating temperature:0~+55°C.
Functional Features Multi-axis pulse motion control. Encoder position feedback. Position comparison and trigger output. Onboard self-diagnosis. Hardware fault LED alarm.
Application Scenarios Precision assembly equipment, semiconductor handling machine, high speed positioning automation platform.
Performance Parameters Max pulse output frequency: 4MHz. Position resolution: 1 pulse. Operating temperature:0~+55°C.
Structural Characteristics Custom printed circuit board, gold-plated connectors, status LED indicators, onboard servo control IC.
Working Principle Receive motion commands from host controller, generate pulse signals to servo drives, read encoder feedback to realize closed-loop positioning control.
Installation Requirements Install inside machine electrical cabinet. Connect servo, encoder and I/O connectors properly. Follow ESD protection procedures.
Usage Notes Operate with anti-static wrist strap during maintenance. Prevent dust and moisture contamination. Avoid physical impact to PCB.
