Technical Specifications Backplane powered. 4 analog output channels. 4-20mA / 0-10V configurable. Galvanic isolation. Operating temperature:0°C ~ +60°C.
Functional Features Analog control signal output. Channel fault detection. Output limiting function. LED status indicator.
Application Scenarios Process control valve regulation, variable frequency drive setpoint control, temperature and pressure continuous adjustment.
Performance Parameters Smooth analog output, high linearity. Operating temperature:0~+60°C.
Structural Characteristics Rack plug-in module, front field wiring terminal, backplane bus connector, digital-to-analog conversion circuit.
Working Principle Receive digital setpoint value from PLC CPU, convert digital signal into analog current or voltage signal to regulate field control valve opening.
Installation Requirements Insert module into Modicon rack. Connect shielded cable to control valve positioner. Download hardware configuration.
Usage Notes Calibrate output zero and span after installation. Do not short output terminals.
