Technical Specifications Backplane power supply. 8 digital output channels. Relay or transistor output type. Group isolation. Operating temperature:0°C ~ +60°C.
Functional Features Discrete control signal output. Overload and short-circuit protection. LED channel status indication.
Application Scenarios Conveyor control, valve interlock, packaging equipment, general industrial automation.
Performance Parameters Reliable switching action, built-in load protection. Operating temperature:0~+60°C.
Structural Characteristics Rack mount plug-in module, front terminal block for field load wiring, backplane bus interface, output drive circuit.
Working Principle Receive logic commands from PLC CPU, switch each output channel on or off to actuate field solenoid valves and relays according to control sequence.
Installation Requirements Install into Modicon 800 rack. Connect field load wiring to terminal block. Download PLC hardware configuration.
Usage Notes Do not exceed rated load current per channel. Add surge suppression for inductive loads.
