Technical Specifications Operating voltage: 24V DC. Contacts: 2 normally open, 2 normally closed. Lock force: 1600N. Operating temperature: -25°C ~ +60°C.
Functional Features Electromagnetic guard locking. Safety contact monitoring. Tamper protection. Door position detection. Certified safety component.
Application Scenarios Robot cell, packaging machine, CNC machine tool safety guard door interlock, machinery safety protection.
Performance Parameters Locking force:1600N. Safety category up to PL e. Operating temperature:-25~+60°C.
Structural Characteristics Metal housing safety switch, actuator tongue, wiring terminal block, locking coil.
Working Principle When machine is running, electromagnetic coil keeps guard door locked; when safety condition met, coil releases locking mechanism to allow door opening, and feedback door status via safety contacts.
Installation Requirements Mount on machine safety guard and frame. Align actuator tongue correctly. Wire safety contacts to safety relay or PLC safety input.
Usage Notes Do not bypass safety interlock function. Regular inspection of locking function and contact wear.
