Technical Specifications 24V DC solenoid power. Safety contact output. IP67 protection. Operating temperature:-25°C ~ +60°C.
Functional Features Solenoid guard locking. Safety contact monitoring. Tamper protection. Door position detection. Safety category compliant contact circuit.
Application Scenarios Machine tool safety guard, packaging machine, robotic cell, automated production line safety door interlock.
Performance Parameters High holding force, safety contact reliable switching. Operating temperature:-25~+60°C.
Structural Characteristics Switch body, solenoid locking mechanism, actuator tongue, cable terminal connector.
Working Principle When machine is running, solenoid keeps the guard door locked. The safety contacts send door status signal to safety relay; only when machine stops, solenoid releases the door for opening.
Installation Requirements Mount switch and actuator on safety guard door frame. Align actuator tongue correctly. Wire 24V solenoid and safety contacts to safety control circuit.
Usage Notes Do not bypass safety switch. Check locking function and contact integrity periodically.
