Technical Specifications Digital control circuit, analog and digital I/O terminals, 24V DC power supply, motor current and voltage monitoring channel.
Functional Features Motor start-stop control, speed adjustment, overcurrent, overload protection, fault alarm and status output.
Application Scenarios Pump control, fan control, small mechanical drive equipment in factory automation.
Performance Parameters Reliable current detection, fast protection response, continuous operation in industrial cabinet environment.
Structural Characteristics DIN rail mount compact module, plastic housing, screw terminals for power, motor and signal wiring.
Working Principle Detects motor operating current and status, executes control logic, outputs drive signals and triggers protection when abnormal condition occurs.
Installation Requirements Mount on DIN rail inside control cabinet, separate power circuit and control signal wiring.
Usage Notes Set overload parameters according to motor nameplate. Power off during wiring work.
