Technical Specifications Fieldbus interface, compatible with E800 inverter backplane, 24V DC auxiliary power, DIN rail or rack installation.
Functional Features Realizes data exchange between inverter and PLC, transmits speed command, status feedback, fault information and parameter access via bus.
Application Scenarios Factory automation production lines, conveyor systems, fan and pump drive control with fieldbus communication.
Performance Parameters Stable bus data transmission, fast status update, built-in communication fault diagnosis.
Structural Characteristics Compact module housing, backplane connector for inverter connection, bus terminal port and status LEDs.
Working Principle Acts as protocol converter between inverter internal bus and external fieldbus, forwards control commands and drive operating data bidirectionally.
Installation Requirements Install on the side of E800 series inverter, lock the backplane connector firmly, wire fieldbus cable with termination resistor.
Usage Notes Power off inverter before module installation. Set correct station address and baud rate according to system.
