Technical Specifications 24V DC power supply. Remote I/O bus interface. Support multiple I/O modules. Operating temperature:0°C ~ +60°C.
Functional Features Remote I/O bus communication. Bus fault monitoring. Data exchange between main PLC and distributed I/O rack. LED link status indicator.
Application Scenarios Large factory distributed automation, long distance field I/O cabinet, conveyor line remote signal collection.
Performance Parameters Stable long-distance bus transmission, fault detection. Operating temperature:0~+60°C.
Structural Characteristics Rack mount adapter module, bus terminal block, backplane connector for local I/O modules, communication processing circuit.
Working Principle Transmit control commands from main PLC to remote I/O modules, collect field signal status from remote I/O rack and send back to PLC over remote I/O bus.
Installation Requirements Install in remote I/O rack. Wire remote bus cable and 24V power. Set station address on module.
Usage Notes Check bus termination resistor. Keep bus cable within maximum length limit.
