Technical Specifications 24V DC power supply. Support Allen‑Bradley Remote I/O protocol. Ethernet TCP/IP interface. Configurable baud rate. Operating temperature: 0°C ~ +60°C.
Functional Features Legacy Remote I/O network conversion. Real-time data mapping between RIO and Ethernet. Network fault diagnosis. Status LED indicators. Support multiple rack addressing modes.
Application Scenarios Factory automation upgrade, legacy Allen‑Bradley PLC system retrofit, production line modernization, oil & gas and water treatment old control system renovation.
Performance Parameters Real-time data transmission, protocol conversion without signal loss. Operating temperature:0~+60°C.
Structural Characteristics DIN rail mount housing, terminal block for power and RIO wiring, Ethernet port, onboard protocol processing circuit.
Working Principle Receive Remote I/O messages from legacy PLC or I/O racks, convert the protocol data into Ethernet packets, and transmit to modern controllers; also convert Ethernet commands back to Remote I/O protocol for field devices.
Installation Requirements Mount on DIN rail inside control cabinet. Wire 24V DC power and Remote I/O bus. Set network address and baud rate via configuration software.
Usage Notes Set proper bus termination resistor. Isolate communication wiring from high-voltage power cables. Backup configuration parameters after setup.
