Pacific Scientific 33VM52-000-29 DC Servo Motor with LDA-196-1000CE Encoder

Technical Specifications Permanent magnet DC structure, LDA-196-1000CE 1000 line incremental encoder, DC power supply, flange mounting form.

Functional Features High torque density, stable speed control, high resolution position feedback, closed-loop positioning.

Application Scenarios Precision automation equipment, testing machine, material handling, special processing machinery.

Performance Parameters Wide speed adjustment range, low vibration, good dynamic response, strong shock resistance.

Material Composition Aluminum alloy housing, permanent magnet rotor, silicon steel stator sheet, alloy output shaft, metal encoder shell.

Structural Characteristics Flange mounted motor body, rear integrated encoder assembly, separate power and feedback signal connectors.

Working Principle DC power drives rotor rotation, encoder converts shaft rotation into pulse signal and feeds back to servo controller to realize closed-loop speed and position control.

Installation Requirements Flange installation, ensure coupling alignment, shielded wiring for encoder cable, good protective grounding.

Usage Notes Avoid shaft impact load. Keep encoder away from oil and dust. Check encoder cable connection regularly.
