Technical Specifications Closed-loop control, pulse/direction command input, built-in encoder feedback, 24V DC control power, phase current adjustable.
Functional Features Position closed-loop control, out-of-step prevention, overload and overheat protection, alarm output and status indication.
Application Scenarios Material handling, small automation stages, dispensing equipment, packaging machinery.
Performance Parameters Eliminates stepper motor lost step issue, stable low-speed operation, simple parameter setup.
Structural Characteristics DIN rail mount compact driver, metal housing, terminal blocks for power, motor and signal wiring.
Working Principle Receives pulse command from motion controller, drives stepper motor, reads built-in encoder to form closed loop and correct position error.
Installation Requirements Mount on DIN rail, wire motor power and encoder cable correctly, separate control signal and power wiring.
Usage Notes Set motor parameters according to motor model. Do not overload motor. Power off before wiring change.
