Technical Specifications Power supplied by FieldPoint backplane. 4 analog output channels. 4-20mA and ±10V voltage output. Channel isolation. Operating temperature:-40°C ~ +70°C.
Functional Features Standard analog control signal output. Output short-circuit protection. Channel fault diagnosis. Status LED indicators. Remote update of output value.
Application Scenarios Distributed process control, remote modulating valve adjustment, VFD speed setpoint control for manufacturing plants.
Performance Parameters High linearity analog output, stable current regulation. Operating temperature:-40~+70°C.
Structural Characteristics DIN rail plastic housing, field wiring terminal block, backplane bus connector, DAC conversion and output drive circuit.
Working Principle Receive digital control values from FieldPoint controller over backplane bus, convert digital data into analog current or voltage signals and send to field control devices.
Installation Requirements Mount on DIN rail. Connect shielded cables to valve positioners or drive analog inputs. Configure output signal type in software.
